7 COMMON WELD SEAM DEFECTS THAT CAUSE FAILURES

Bad seams do not always fail right away

Most weld seam failures start small. A seam might look fine today and still be weak underneath due to a defect or poor fusion. Then a hard bump on the Yellowhead, vibration on a gravel road outside the city, or a heavy load shift turns that small weakness into a crack or a break.

Knowing the common defects helps you spot trouble early and avoid repeat repairs. It also helps you understand why one weld lasts years and another fails after one season. Below are the seam issues we see most often on trailers, gates, brackets, racks, and equipment repairs around Edmonton and the surrounding area.

The 7 seam defects that cause most failures

1) Lack of fusion

The bead is present, but it never truly fused into the base metal. Under load, the seam can peel or shear along the fusion line. Lack of fusion is often linked to low heat input, poor angle, moving too fast, or welding over contamination.

2) Cold lap or overlap

Cold lap is when weld metal rolls onto the base metal without bonding properly. It often creates a bead that looks smooth but sits on top. Cold lap is a common reason cracks form along the toes of the weld, especially in vibration zones.

3) Porosity

Porosity shows up as pinholes or a pitted texture. It can be caused by contamination, poor shielding, or windy conditions in outdoor work. Porosity weakens the seam and can trap moisture, accelerating corrosion during Edmonton winter and spring.

4) Undercut

Undercut looks like a groove melted into the base metal along the edge of the seam. It reduces the thickness of the parent material and creates a stress riser where cracks start. Undercut is a frequent issue on high-stress brackets and trailer components.

5) Cracking, including crater cracks

Cracks can appear at the toe, along the seam, or at the end of a bead where the weld was stopped. Crater cracks are a classic failure point because they start small and grow with vibration. If you see a hairline crack, it usually gets worse, not better.

6) Inclusions

Inclusions are trapped material inside the seam, such as slag from previous passes. They reduce strength and can create hidden weak points that later open up under load. Even when the surface bead looks decent, inclusions can cause early failure.

7) Poor fit-up and gaps

This one is not strictly a bead defect, but it leads to bead defects. When parts do not fit tight, the seam often ends up bridging gaps instead of properly fusing a joint. That can cause lack of fusion, burn-through on thin material, and a seam that looks heavy but is structurally wrong.

If the seam is failing, the problem is usually fusion, contamination, or joint design. Adding more bead on top rarely fixes the root cause.

Quick table: what you see vs what it usually means

Why Edmonton conditions make defects worse

Cold, salt, and moisture do not create the defect, but they make a defect fail sooner. A porous seam holds moisture. An undercut edge rusts faster. A weak fusion line can survive light use and then break after one rough winter. If you tow or haul year-round, seam quality matters even more.

What to do if you suspect a defect

• If it is load-bearing, stop using it until it is assessed.
• Look for rust bleeding out of a seam line, which often tracks cracks or gaps.
• Avoid quick patch welds over an existing crack. The crack usually needs to be removed and rebuilt properly.
